Brass Macaroni Insert — PTFE (Teflon) Lined
Replaceable brass macaroni insert with a PTFE (Teflon) lining, for fitting into a macaroni die plate.
View details
Photo 1 of 3: R.N. stainless-steel macaroni die plate fitted with rings of PTFE-lined inserts
1 / 3Macaroni Dies
Macaroni Die — Plain or PTFE-Lined Inserts
Die plate fitted with replaceable brass macaroni inserts, available plain or PTFE (Teflon)-lined, for consistent elbow and straight macaroni.
- Die material
- Stainless steel (Grade 304) or brass
- Insert options
- Plain or PTFE (Teflon)-lined
- Extruder capacity range
- Designed for machines of about 150–200 kg/hr
Pasta shapes
- Elbow macaroni
- Straight macaroni (tubes)
Price on request — depends on size, material and quantity.
Overview
A macaroni die sits at the head of the extruder. Dough is pressed through each insert, where a central pin forms the hollow tube; the insert geometry sets the diameter, wall thickness and curve of the macaroni.
R.N. supplies macaroni dies as a plate fitted with replaceable inserts, made to suit your extruder. Inserts can be plain or lined with PTFE (Teflon). Lined inserts generally give a smoother, glossier surface; unlined metal gives a rougher, matt surface that holds sauce. The photograph shows an R.N. die plate fitted with lined inserts.
Applications
- Elbow macaroni production in food manufacturing units
- Replacing a worn die on an existing extruder
- Switching between plain and PTFE-lined finishes
Technical specifications
| Die material | Stainless steel (Grade 304) or brassAs stated by R.N. |
|---|---|
| Insert options | Plain or PTFE (Teflon)-lined |
| Extruder capacity range | Designed for machines of about 150–200 kg/hrAs stated by R.N. — confirm for your machine |
| Outer diameter | Contact for specifications |
| Number of inserts | Contact for specifications |
| Macaroni size and wall thickness | Contact for specifications |
Values marked “Contact for specifications” depend on your machine and order. R.N. will confirm them with your quotation.
Available materials
- Stainless steel (Grade 304) or brass
- Brass inserts
- PTFE (Teflon) insert lining — optional
Dimensions and machine compatibility
Dies are made to fit the die head of your extruder. Share the machine make and model, the die-seat diameter and thickness and the clamping arrangement — or send your existing die or a drawing — so the new die matches your machine.
Customisation options
Plate size, insert count, insert size and lined or unlined inserts are specified per order.
Maintenance
General guidance: clean the die after every production run, before dough dries inside the openings — soak in warm water and clear residue with soft, non-metallic tools, taking particular care not to scratch PTFE linings. Dry thoroughly before storage. Inspect inserts regularly for wear or damaged linings and replace individual inserts when needed. Always follow any care instructions supplied with your die.
